One-touch connector
Connect the scope in a single action. Use the waterproof cap when reprocessing, following the manufacturer’s instructions.
MEDINTECH
Motorized video gastroscope
MGS-400
Two wheels control vertical and horizontal angulation. Configurable electronic buttons bring key functions to the control body.
Enquire & request a quotation
Instrument channel
A 2.8 mm channel accommodates endoscopic accessories during examination and intervention.
Controlled angulation
Up 210°, down 90° and left/right 100°. Supports air, water and suction.
Full HD imaging
Full HD endoscopic imaging with the compatible imaging system.
MGS-400
Technical specifications
| Field of view | 140° |
|---|---|
| Direction of view | Forward viewing |
| Depth of field | 5–100 mm |
| Distal end outer diameter | 10.0 mm |
| Insertion tube outer diameter | 9.9 mm |
| Working length | 1,030 mm |
| Instrument channel inner diameter | 2.8 mm |
| Angulation up / down | 210° / 90° |
| Angulation left / right | 100° / 100° |
| Total length | 1,350 mm |
Compatible equipment
Configurations, options and availability are confirmed for each enquiry. Contact Astra Medi for documentation and advice.
